首页 > 水泵系列 > 離心泵
NCP
CENTRIFUGAL PUMP

Operating conditions:
Max .working pressure 10 bar
Liquid temperature up to 35℃
Ambient temperature up to 40℃
Total suction lift up to 8mt.
Continuous duty
Motor:
Two-pole induction motor(n=2900r.p.m.)
Insulation class B/F
Protection IP44
Material:
Pump body: cast iron
Motor support: cast iron]
Impeller: nory/stainless steel
Suffuser: noryl
Pump casing: stainless steel
Shaft with rotor: Hi-Cr plated 45# steel/stainless
steel
Mechanical seal: Carbon/Ceramic
Application:
Centrifugal horizaontal multi-impeller water
pumps able to develop high pressure and a high
water lift with a comparatively low power
consumption.
Silent runing and very good features,they are
suitable in domestic fittings by tank pressure
groups,for small sprinkler irrigations and car
washing.
PERFORMANCE DATA at n=2900r/min

MODEL

POWER

Impeller

Inlet/outlet

Max.Flow

Max.head

Max.suct

GW(kg)

Dimension

Qty/20FT

KW

HP

L/min

(m)

(m)

(mm)

(unit)

3NCP100S

0.6

0.8

3

1"×1"

100

32

8

12

420×190×230

1400

4NCP100S

0.75

1

4

1"×1"

100

44

8

13.5

445×242×280

900

5NCP100S

0.9

1.25

5

1"×1"

100

56

8

15

470×250×305

800
