Applications For water supply from wells or reservoirsFor domestic use, for civil and industrial applications For garden use and irrigation
Operating conditions Water temperature up to 40℃Maximum immersion depth:10MMotor Three-phase:230V±10%(220-240V)Three-phase:440V±10%(380-415V)Single-phase:230V±10% (220-240V)With electronic off-centre switch(above 1.5KW)The starting torque is 1.8-2.5
Special feature on request Other voltages. Frequency 50-60Hz.Other mechanical seal.Cable gland with cable fasteners
MODEL
POWER
MAX.HEAD
MAX.FLOW
Dimension(mm)
Out
KW
HP
m
L/min
NDPS1500
1.5
2
16
467
450×320×280
2"
NDPS2200
2.2
3
20
750
500×350×300
2"/3"
NDPS3000
4
25
833
600×400×350
3"
NDPS4000
5.5
31
1166
